Please note that this documentation is for the most recent version of this extension. It may not be relevant for older versions. Related documentation can be found in the documentation directory of the extension.
Fluid FPDF ViewHelpers
fpdf:addFont
Imports a TrueType, OpenType or Type1 font and makes it available. It is necessary to generate a font definition file first with the MakeFont utility. The definition file (and the font file itself when embedding) must be present in the font directory. If it is not found, the error "Could not include font definition file" is raised.
Parameter
| Name | Type | Default | Description |
|---|---|---|---|
| family | string | Font family. The name can be chosen arbitrarily. If it is a standard family name, it will override the corresponding font. | |
| style | string | Font style. (N: regular, B: bold, I: italic) | |
| filename | string | The font definition file. By default, the name is built from the family and style, in lower case with no space. |
Return
void
Usage:
<fpdf:setFont family="Arial" style="B" size="10.5" />fpdf:pdf
Creates a new PDF.
Parameter
| Name | Type | Default | Description |
|---|---|---|---|
| filename | string | FluidFpdf.pdf | The name of the file |
| destination | string | I | Destination where to send the document. It can take one of the following values: I, D, F, S |
| orientation | string | P | Default page orientation. |
| unit | string | mm | User unit. |
| size | string | A4 | The size used for pages. |
| title | string | Fluid-Fpdf | Defines the title of the document. |
| subject | string | Fluid-Fpdf | Defines the subject of the document. |
| author | string | Fluid-Fpdf | FDefines the author of the document. |
| keywords | string | TYPO3 Fluid FPDF typo3(at)coding(dot)ms | Associates keywords with the document, generally in the form 'keyword1 keyword2 ...'. |
| fontPath | string | EXT:fluid_fpdf/Resources/Private/Fonts | Defines the font path for the included fonts (for example: EXT:fluid_fpdf/Resources/Private/Fonts) or some TYPO3 path like /fileadmin/fonts/ |
| imagePath | string | EXT:fluid_fpdf/Resources/Private/Images | Defines the image path for the included images (for example: EXT:fluid_fpdf/Resources/Private/Images) or some TYPO3 path like /fileadmin/fonts/ |
| characterMap | array | Defines a character map, for mapping characters. For Example, for mapping €-character with character at ASCII-No. 162, use {162: '€'} |
Return
void
Usage:
<fpdf:pdf>
<fpdf:addPage orientation="P" size="A4">
// Your PDF content...
</fpdf:addPage>
</fpdf:pdf>fpdf:setFont
Sets the font used to print character strings.
Parameter
| Name | Type | Default | Description |
|---|---|---|---|
| family | string | Arial | Family font. |
| style | string | N | Font style. (N: regular, B: bold, I: italic, U: underline) |
| size | string | 12 | Font size in points. |
Return
void
Usage:
<fpdf:setFont family="Arial" style="B" size="10.5" />fpdf:setSourceFile
Set the source file for PDF page templates.
Parameter
| Name | Type | Default | Description |
|---|---|---|---|
| file | string | EXT:fluid_fpdf/Resources/Private/Pdf/TYPO3_2012-logo_sRGB_color.pdf | Filename with abs path of the source |
Return
int - Number of pages found in source file
Usage:
<fpdf:setSourceFile file="EXT:fluid_fpdf/Resources/Private/Pdf/Normbriefbogen_DIN5008.pdf" />fpdf:useTemplate
Prints a PDF-Template into a page
Parameter
| Name | Type | Default | Description |
|---|---|---|---|
| pageNo | int | The page number | |
| x | int | The x-position | |
| y | int | The y-position | |
| w | int | The new width of the template | |
| h | int | The new height of the template | |
| adjustPageSize | boolean | false | If set to true the current page will be resized to fit the dimensions of the template |
Return
void
Usage:
<fpdf:useTemplate pageNo="1" x="0" y="0" w="0" h="0" adjustPageSize="0" />
TYPO3 Fluid-FPDF
This extension provides you a complete set of ViewHelpers for dealing with FPDF by using Fluid. You can use the ViewHelpers easily in own Extensions just by defining the fpdf-Namespace. Additionally you're able to use the build in plugin, for displaying predefined PDF. This plugin offers you automatically all available PDFs.
